ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR

Shenzhen Guangtongdian Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR from wholesalers

    Buy cheap ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR from wholesalers
    • Buy cheap ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR from wholesalers

    ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR

    Ask Lasest Price
    Brand Name : GTD
    Model Number : HK-8252-1096-1
    Price : contact me
    Payment Terms : T/T,L/C
    Supply Ability : 500,000pcs/month
    Delivery Time : 15 - 25 days after receipt of deposit / full amount
    Certification : IATF 16949, ISO 9001
    • Product Details
    • Company Profile

    ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR

    Vehicle Camera Lenses RVC series:131.3°HFOV with 1.3MP short TTL Lens


    Product Details

    SPECIFICATIONJZ-9198
    SENSOR SIZEOX01G10(1280*800*3)
    WAVELENGTHλ 400-700nm(COLOR)
    FOCAL LENGTH (EFL)f 1.28 mm
    F/NO (INFINITE)F/NO 2.0
    BACK FOCAL LENGTHBFL 2.3 mm
    FLANGE BACK LENGTHFB 1.85 mm
    FIELD OF VIEW (DIAGONAL)D 147.5° H 131°V 91.9°
    OPTICAL DISTORTION.-43.4%
    THREAD SIZEM12*P0.5,Ø10(AA)
    ELEMENT2G4P+1IR


    Product features

    1. High definition lenses with optical filter.

    2. Can be used in multiple field:

    • Security Surveillance
    • Unmanned Aerial Vehicles (UAVs)
    • Action Cameras
    • Industrial Inspection
    • Medical Imaging
    • Virtual Reality (VR) and Augmented Reality (AR)
    • Smart Home
    • Robot Vision
    • Traffic Monitoring
    • Underwater Photography

    Lens production inspection process

    Quality Guarantee

    car camera drop-ball standard

    salt spray test

    waterproof test

    against UV light

    IP6K9K

    IP68

    ROHS

    film strength's resistance to scratch


    ROHS M12xP0.5 Reverse rearview Lenses 1MP/1.3MP High Definition with 131.3° wide Angle and 2G4P+1IR

    Why Choose Us

    1. Strength Factory: Top10 optical lenses manufacturers in China. More than 18 years manufacturing experience, multi-production lines to guarantee quick delivery.

    2. Professional Team: We own more than 95 engineers in the research and development team. By 2024, 177 patents had been granted. Equipped with automated production line, master all the core manufacturing industry chain.

    3. High Quality: With the advanced metrology instruments and impeccable quality assurance system, AICO was ISO9001, ISO/TS 16949 and ISO 14001 certified with SGS.
